Semi-automatic solder paste printing machine
1. Semi-automatic high precision solder paste printing machine adopts Taiwan silver precision linear guide rail and stepless speed regulation motor to drive the scraper base to ensure printing accuracy. 2. microcomputer control, touch screen display, menu operation interface, simple, convenient and more suitable for man-machine dialogue 3. Semi-automatic solder paste printing machine scraper floats. (Similar to a fully automatic printing machine, the scraper can float up and down freely and automatically adjust the level of the steel mesh). 4. Semi-automatic printing machine printing blade can be adjusted, can also be rotated up 45 degrees fixed (easy to clean and replace printing screen and scraper) 5. The pressure of the scraper is adjustable, (the pressure of the scraper on the steel mesh can be adjusted according to the length of the different type of scraper). 6. The working operation adopts two-hand key switch operation, which is safe and reliable. 7.The touch screen menu of the printing press can independently set the left up and left down stop time of the scraper, the right up and right down stop time, and the overall stop and stop time of the steel mesh. 8. Solder paste printing machine table is equipped with a magnetic honeycomb platform, and the positioning and fixing methods of the PCB board include reference hole positioning, reference side positioning and reference hole and reference side positioning at the same time, template positioning and other different accurate positioning forms. 9. The touch screen is equipped with time display function, automatic counting of printing times and screen protection function. 10. Solder paste printing machine with left and right scraper speed adjustable function and emergency stop safety function. 11. The suspension scraper system makes printing more flexible, and the scraper can float up and down freely and automatically adjust the level of the steel mesh 12. The printing machine can set one-way and two-way printing, a variety of printing methods. (Printing times set freely) 13. The printing press has three working states: automatic, semi-automatic and point-moving, point-moving is mainly easy to adapt to the adjustment at the beginning. Each action can be adjusted independently. 14. The alarm function of the clean steel mesh is convenient for quantitative scrubbing of the mesh board and ensuring the printing quality.
Semi-automatic solder paste printing machine parameters:
Semi-automatic solder paste printing machine feature：
